Summary
| Description |
Deutsch: Hochfrequenz 309 ist die einzige Aufschrift auf diesem Gerät das mehr oder weniger lange vor 1956 gebaut wurde. Die Metadaten zu diesem Bild sind völlig falsch, aber leider kann man sie hier nicht verändern. Benutzer:Karl Bednarik fotografiert am 3. Dezember 2006, es wurden drei Fotos mit Microsoft Paint vereinigt: In der Bildmitte sieht man das violett leuchtende Argon und am unteren Rand sieht man das Innenleben des Gerätes mit dem Wagnerschen Hammer in der Mitte, dessen mechanische Amplitude durch eine Stellschraube geregelt wird.
English: A violet ray appliance, an antique quack medical device from the early 20th century for applying high voltage, high frequency electric current to the body. It consists of a high voltage Tesla transformer in the box, connected to the glass electrode (left). When turned on, the electrode tube gave off a violet glow (inset, center). It was applied to various parts of the body to treat different complaints. RF 309 is the only inscription on this device that was built more or less long ago in 1956. The metadata for this picture are completely wrong, but unfortunately you can not change it here. User: Karl Bednarik photographed on 3 December 2006 it was combined with Microsoft Paint three photos: In the middle you see the purple glowing argon and at the bottom you can see the inner workings of the device with the Wagner's hammer in the middle, the mechanical amplitude is governed by a set screw. |
| Date | 3 December 2006 (original upload date) |
| Source | Transferred from de.wikipedia to Commons using CommonsHelper. |
| Author | The original uploader was Karl Bednarik at German Wikipedia. |
- Hochfrequenz 309
-
Glas-Sonde und Gehäuse mit Tesla-Transformator -
Glas-Sonde mit violett leuchtendem Argon -
Innenleben des Gerätes mit Wagnerschem Hammer -
Kombiniertes, verkleinertes Bild
